We have a SQL Server DB that contains a large table (>100M rows) with archive values, basically in the form of [Id], [StationId], [DatapointId], [Timestamp], [Value]. As the stations do not get polled, there aren't any regular intervals at which a station sends a datapoint, so the timestamps are set to arbitrary times.

For our web visualization, I need to extract entries from this table for a pannable chart that I'm building with D3.js. I need to query by StationId, DatapointId, StartDate and EndDate. This is simple and works as expected, but for the line chart that it feeds, I do need additional data, namely the first value before the chosen time interval, and (if there is one) the first value after the interval. This is neccessary to draw the line from the left resp. right boundary of the chart to the first/last value within the interval (otherwise the data within the chart would look somewhat "isolated" because the line stops before the charts boundaries, like there's no data before or after the values in the chosen interval).

At the moment I need to run 3 queries: one to get the data within the interval, one to retrieve the first matching row before StartDate, and anotherone to get the first matching row after EndDate.

It works, and after creating a covering index the speed is ok, but I think there might be a way to reduce the number of roundtrips to the DB. Do you have any idea?

I assume you query for all data (from all stations) in a specific time range.

You can probably write this with window functions (and it might be more efficient) but here is one method, with OUTER APPLY.

(The ds subquery is only used to get a list of distinct StationID. It should be replaced with the Stations table you likely have):

SELECT

    ds.[StationID],                   -- station

    st.ExtendedStartDate,             -- extended start and

    en.ExtendedEndDate                -- and end dates



    tt.[Timestamp],                   -- timestamps and data

    tt.[DatapointId],

    tt.[Value]

FROM

    ( SELECT DISTINCT [StationID]

      FROM ArchiveTable

    ) AS ds

  OUTER APPLY

    ( SELECT TOP (1) s.[Timestamp] AS ExtendedStartDate

      FROM ArchiveTable AS s

      WHERE s.[StationId] = ds.[StationId]

        AND s.[Timestamp] < @StartDate

      ORDER BY s.[Timestamp] DESC

    ) AS st

  OUTER APPLY

    ( SELECT TOP (1) e.[Timestamp] AS ExtendedEndDate

      FROM ArchiveTable AS e

      WHERE e.[StationId] = ds.[StationId]

        AND e.[Timestamp] > @EndDate

      ORDER BY e.[Timestamp] ASC

    ) AS en

  OUTER APPLY

    ( SELECT t.*

      FROM ArchiveTable AS t

      WHERE t.[StationId] = ds.[StationId]

        AND t.[Timestamp] >= COALESCE(st.ExtendedStartDate, @StartDate)

        AND t.[Timestamp] <= COALESCE(en.ExtendedEndDate, @EndDate)

    ) AS tt ;

Taking roundtrips to the database should not be an issue, if you want to send them to the db as one query, you could do that by using CTE's and UNION ALL operators.

I need to query for a single StationId and a single DatapointId at a
time

The query below filters on StationId, DatapointID and the StartDate and EndDate using the timestamp column.

--Filter params



DECLARE @startdate datetime2 = '2019-02-20 8:48:08.633'

DECLARE @EndDate datetime2 = '2019-02-20 10:48:08.633'

DECLARE @stationid int = 1

DECLARE @DatapointId int = 1



--Query



;WITH CTE AS

(

SELECT TOP(1) [StationId],[DatapointId],[TimeStamp]

FROM PollingTable

WHERE [TimeStamp] < @startdate

      AND StationId =  @stationId

      AND [DatapointId] = @Datapointid

ORDER BY [TimeStamp] desc

)

,CTE2 AS

(

SELECT TOP(1) [StationId],[DatapointId],[TimeStamp]

FROM PollingTable

WHERE [TimeStamp] > @EndDate

      AND StationId =  @stationId

      AND [DatapointId] = @Datapointid

ORDER BY [TimeStamp] asc

)

SELECT [StationId],[DatapointId],[TimeStamp]

FROM CTE

UNION ALL

SELECT [StationId],[DatapointId],[TimeStamp]

FROM PollingTable

WHERE [TimeStamp] >= @startdate

      AND [TimeStamp] <= @EndDate

      AND StationId =  @stationId

      AND [DatapointId] = @Datapointid

UNION ALL

SELECT [StationId],[DatapointId],[TimeStamp]

FROM CTE2;

Afterwards, this index was added

CREATE INDEX IX_StationId_DatapointId_TimeStamp on PollingTable(StationId,DatapointId,TimeStamp)

Resulting in seeks on my end, but you might have to swap columns around depending on how your dataset is distributed. My dataset is nowhere near yours.
