How to get a 2D Plot from a 3D Listplot?

Efficient Data Entry / Manipulation with Many DatasetsVisual representation of a Ranking over time (image provided)How to plot a 3D surface from an Excel matrix, using column and row headers as axis labelsCreating a custom color plot with tones of colorsHow can I get the interpolation line from Listplot?Plotting data imported from CSV fileInserting columns into a large table of data and converting it into a {x,y,z} listHow to plot imaginary parts of complex valued list of data separately?Labeling a list plot came from excel data setHow to plot 3D discontinuous iterative plot?

1

$begingroup$

I have the following ListPlot3D , where C is specific Heat , T temperature and n concentration, my list first column present n, second T and third column is for C.
I have this code to plot 3D graph from file name "data"

data = PadLeft[Import["E:\new_n\T(n).dat", "Table"]];

d = ListPlot3D[data, PlotRange -> Full, AxesLabel -> {n, T, C},

   PlotStyle -> Green]

List in the link

Is it possible to get 2D graph from 3d listPlot? Could you please help me?

Any suggestions are very appreciated.

plotting

share|improve this question

edited 4 hours ago

kglr

185k10202421

asked 4 hours ago

Тахер БенТахер Бен

353

$endgroup$

•















  $begingroup$
  How do you want to get the 2D plot? Along which axis? What view point? Can you just project onto the XY plane? Onto the XZ plane? We'll need more info to help you
  $endgroup$
  – b3m2a1
  3 hours ago








•















  $begingroup$
  @b3m2a1 i want to plot T(c) plane xy
  $endgroup$
  – Тахер Бен
  3 hours ago









add a comment |

1

$begingroup$

I have the following ListPlot3D , where C is specific Heat , T temperature and n concentration, my list first column present n, second T and third column is for C.
I have this code to plot 3D graph from file name "data"

data = PadLeft[Import["E:\new_n\T(n).dat", "Table"]];

d = ListPlot3D[data, PlotRange -> Full, AxesLabel -> {n, T, C},

   PlotStyle -> Green]

List in the link

Is it possible to get 2D graph from 3d listPlot? Could you please help me?

Any suggestions are very appreciated.

plotting

share|improve this question

edited 4 hours ago

kglr

185k10202421

asked 4 hours ago

Тахер БенТахер Бен

353

$endgroup$

•















  $begingroup$
  How do you want to get the 2D plot? Along which axis? What view point? Can you just project onto the XY plane? Onto the XZ plane? We'll need more info to help you
  $endgroup$
  – b3m2a1
  3 hours ago








•















  $begingroup$
  @b3m2a1 i want to plot T(c) plane xy
  $endgroup$
  – Тахер Бен
  3 hours ago









add a comment |

$begingroup$

I have the following ListPlot3D , where C is specific Heat , T temperature and n concentration, my list first column present n, second T and third column is for C.
I have this code to plot 3D graph from file name "data"

data = PadLeft[Import["E:\new_n\T(n).dat", "Table"]];

d = ListPlot3D[data, PlotRange -> Full, AxesLabel -> {n, T, C},

   PlotStyle -> Green]

List in the link

Is it possible to get 2D graph from 3d listPlot? Could you please help me?

Any suggestions are very appreciated.

plotting

share|improve this question

edited 4 hours ago

kglr

185k10202421

asked 4 hours ago

Тахер БенТахер Бен

353

$endgroup$

data = PadLeft[Import["E:\new_n\T(n).dat", "Table"]];

d = ListPlot3D[data, PlotRange -> Full, AxesLabel -> {n, T, C},

   PlotStyle -> Green]

share|improve this question

edited 4 hours ago

kglr

185k10202421

asked 4 hours ago

Тахер БенТахер Бен

353

share|improve this question

edited 4 hours ago

kglr

185k10202421

asked 4 hours ago

Тахер БенТахер Бен

353

edited 4 hours ago

kglr

185k10202421

edited 4 hours ago

kglr

185k10202421

asked 4 hours ago

Тахер БенТахер Бен

353

asked 4 hours ago

Тахер БенТахер Бен

353

2 Answers
2

active

oldest

votes

2

$begingroup$

You may use ListContourPlot. Also, you may want to have a look at the ColorFunction option of these functions.

With data as in OP. Then

ListContourPlot[data,

 PlotRange -> Full,

 FrameLabel -> {n, T},

 PlotLegends -> Automatic,

 ColorFunction -> ColorData[{"StarryNightColors", "Reverse"}]

 ]

Hope this helps.

share|improve this answer

answered 3 hours ago

EdmundEdmund

26.5k330102

$endgroup$

add a comment |

1

$begingroup$

data = PadLeft[Import["E:\new_n\T(n).dat", "Table"]];

T = data[[All, 2]]; c = data[[All, 3]];

ListPlot[Table[{c[[i]], T[[i]]}, {i, 1, Length[c]}],

 AxesLabel -> {"c", "T"}, PlotRange -> All]

share|improve this answer

answered 2 hours ago

Alex TrounevAlex Trounev

7,5181421

$endgroup$
